Mellow-3D behemoth - Voron Trident - Bill of material
Version: 1.00 / 30.04.2026
behemoth - Set1: X1 & Y1 Motor Mount
Aluminium Parts
| Quantity |
Description |
Link |
| 1x |
SET 1 - behemoth X1 top motor mount |
Mellow 3D |
| 1x |
SET 1 - behemoth X1 bottom motor mount |
|
| 1x |
SET 1 - behemoth Y1 top motor mount |
|
| 1x |
SET 1 - behemoth Y1 bottom motor mount |
|
Screws
| Quantity |
Description |
| 4x |
M3x5mm SHCS |
| 14x |
M3x6mm SHCS |
| 2x |
M3x10mm SHCS |
| 6x |
M3x55mm SHCS |
| 4x |
M5x15mm SHCS |
| 16x |
M5x20mm SHCS |
| 2x |
Sholder bolt 50mm: Shoulder Diameter (d) 5mm / Thread Size 4mm |
Flanged Ball Bearings
| Quantity |
Description |
| 2x |
625 for 5mm Motor Shaft |
| 2x |
688 for 8mm Motor Shaft NOT INCLUDED IN THE KIT |
Aluminium Bushings
| Quantity |
Description |
| 6x |
M3 Bushing 3.1mm ID x 6mm OD x 30mm |
Drop-in T-nut
| Quantity |
Description |
| 20x |
M5 T-nut |
behemoth - Set2: X & Y Motor Mount
Aluminium Parts
| Quantity |
Description |
Link |
| 1x |
SET 2 - behemoth X top motor mount |
Mellow 3D |
| 1x |
SET 2 - behemoth X bottom motor mount |
|
| 1x |
SET 2 - behemoth Y top motor mount |
|
| 1x |
SET 2 - behemoth Y bottom motor mount |
|
Screws
| Quantity |
Description |
| 4x |
M3x5mm SHCS |
| 6x |
M3x6mm SHCS |
| 2x |
M3x10mm SHCS |
| 6x |
M3x55mm SHCS |
| 4x |
M5x15mm SHCS |
| 8x |
M5x20mm SHCS |
Flanged Ball Bearings
| Quantity |
Description |
| 2x |
625 for 5mm Motor Shaft |
| 2x |
688 for 8mm Motor Shaft NOT INCLUDED IN THE KIT |
Aluminium Bushings
| Quantity |
Description |
| 6x |
M3 Bushing 3.1mm ID x 6mm OD x 30mm |
Drop-in T-nut
| Quantity |
Description |
| 12x |
M5 T-nut |
behemoth - Set3: X1 & Y1 Idler Pack
Aluminium Parts
| Quantity |
Description |
Link |
| 1x |
SET 3 - behemoth X1 top idler pack |
Mellow 3D |
| 1x |
SET 3 - behemoth X1 bottom idler pack |
|
| 1x |
SET 3 - behemoth Y1 top idler pack |
|
| 1x |
SET 3 - behemoth Y1 bottom idler pack |
|
| 2x |
SET 3 - behemoth Y1 bottom idler pack brace |
|
Screws
| Quantity |
Description |
| 2x |
M2x10mm SHCS |
| 4x |
Low-Profile M3x8mm |
Flanged Ball Bearings
| Quantity |
Description |
| 16x |
MF115ZZ for 5mm Live Idler Shaft |
behemoth - Set4: Idler Pack Tension Arms
Aluminium Parts
| Quantity |
Description |
Link |
| 2x |
SET 4 - behemoth idler pack tension arm |
Mellow 3D |
Screws
| Quantity |
Description |
| 2x |
M4x25mm SHCS |
Flanged Ball Bearings
| Quantity |
Description |
| 4x |
MF115ZZ for 5mm Live Idler Shaft |
h6 Precision dowel pins
| Quantity |
Description |
| 2x |
h6 Precision dowel pins M5x45mm |
Precision shims
| Quantity |
Description |
| 4x |
Precision shims M5x7x1mm |
Cross Hole Hammer Nuts
| Quantity |
Description |
| 2x |
M4x25mm Hammer Nut |
behemoth - Set5: X & Y Idler Pack
Aluminium Parts
| Quantity |
Description |
Link |
| 1x |
SET 5 - behemoth X top idler pack |
Mellow 3D |
| 1x |
SET 5 - behemoth X bottom idler pack |
|
| 1x |
SET 5 - behemoth Y top idler pack |
|
| 1x |
SET 5 - behemoth Y bottom idler pack |
|
Flanged Ball Bearings
| Quantity |
Description |
| 4x |
MF115ZZ for 5mm Live Idler Shaft |
behemoth - Set6: XY Joiners
Aluminium Parts
| Quantity |
Description |
Link |
| 1x |
SET 6 - behemoth XY-joiner A top |
Mellow 3D |
| 1x |
SET 6 - behemoth XY-joiner A bottom |
|
| 2x |
SET 6 - behemoth XY-joiner AB middle |
|
| 1x |
SET 6 - behemoth XY-joiner B top |
|
| 1x |
SET 6 - behemoth XY-joiner B bottom |
|
Screws
| Quantity |
Description |
| 8x |
Low-Profile M3x5mm |
| 8x |
Low-Profile M3x8mm |
| 6x |
M5x18mm SHCS |
Flanged Ball Bearings
| Quantity |
Description |
| 8x |
MF115ZZ for 5mm Live Idler Shaft |
Tip
X-axis SET7 and SET8 are ideal for high-speed 3D printing and chamber temperatures up to 60 °C. If you’re looking for a high-temperature (up to 100C) X-axis, choose SET9–SET11 depending on your 3D printer size.
behemoth - Set7: High Speed X-axis for Voron 300
Aluminium Parts
| Quantity |
Description |
Link |
| 1x |
SET 7 - behemoth 300 X axis high-speed |
Mellow 3D |
behemoth - Set8: High Speed X-axis for Voron 350
Aluminium Parts
| Quantity |
Description |
Link |
| 1x |
SET 8 - behemoth 350 X axis high-speed |
Mellow 3D |
behemoth - Set9: High-temperature X-axis for Voron 300
Stainless steel Parts
| Quantity |
Description |
Link |
| 1x |
SET 9 - behemoth 300 X axis high-temp |
Mellow 3D |
behemoth - Set10: High-temperature X-axis for Voron 350
Stainless steel Parts
| Quantity |
Description |
Link |
| 1x |
SET 10 - behemoth 350 X axis high-temp |
Mellow 3D |
behemoth - Set11: High-temperature X-axis for Voron 400
Stainless steel Parts
| Quantity |
Description |
Link |
| 1x |
SET 11 - behemoth 400 X axis high-temp |
Mellow 3D |
Warning
Please note that you are ordering SET13 – behemoth VT frame brace.
SET12, designed for V24 3D printers, will not fit.
behemoth - Set13: Frame Brace
Aluminium Parts
| Quantity |
Description |
Link |
| 2x |
SET 13 - behemoth VT Frame Brace A1 |
Mellow 3D |
| 2x |
SET 13 - behemoth VT Frame Brace A2 |
|
| 2x |
SET 13 - behemoth VT Frame Brace B1 |
|
| 2x |
SET 13 - behemoth VT Frame Brace B2 |
|
Screws
| Quantity |
Description |
| 8x |
M5x10mm SHCS |
| 8x |
M5x20mm SHCS |
Drop-in T-nut
| Quantity |
Description |
| 8x |
M5 T-nut |
Warning
Before ordering live idlers for your 3D printer, confirm whether your build uses 9 mm or 12 mm belts. The live idlers are press-fitted and difficult to replace, so choosing the correct size is important. If you order the wrong version, you will need to purchase the correct one.
SET14 and SET15 are designed for 9 mm belts.
SET16 and SET17 are designed for 12 mm belts.
behemoth - Set14: Live Idler 9mm with teeth
Live Idler
| Quantity |
Description |
Link |
| 6x |
SET 14 - behemoth live idler 9mm with teeth |
Mellow 3D |
behemoth - Set15: Live Idler 9mm without teeth
Live Idler
| Quantity |
Description |
Link |
| 8x |
SET 15 - behemoth live idler 9mm without teeth |
Mellow 3D |
behemoth - Set16: Live Idler 12mm with teeth
Live Idler
| Quantity |
Description |
Link |
| 6x |
SET 16 - behemoth live idler 12mm with teeth |
Mellow 3D |
behemoth - Set17: Live Idler 12mm without teeth
Live Idler
| Quantity |
Description |
Link |
| 8x |
SET 17 - behemoth live idler 12mm without teeth |
Mellow 3D |
Warning
Please note before ordering: the behemoth use brass pulleys for increased strength and reduced wear compared to aluminum. Aluminum pulleys are still supported if you prefer that option.
The gantry supports 9 mm and 12 mm belts, as well as 5 mm or 8 mm motor shafts. Please confirm your motor shaft size and belt width before placing your order.
behemoth - Set18: Brass M5x9mm belt pulley
Brass pulley
| Quantity |
Description |
Link |
| 4x |
SET 18 - behemoth brass M5x9mm belt pulley |
Mellow 3D |
behemoth - Set19: Brass M5x12mm belt pulley
Brass pulley
| Quantity |
Description |
Link |
| 4x |
SET 19 - behemoth brass M5x12mm belt pulley |
Mellow 3D |
behemoth - Set20: Brass M8x9mm belt pulley
Brass pulley
| Quantity |
Description |
Link |
| 4x |
SET 20 - behemoth brass M8x9mm belt pulley |
Mellow 3D |
behemoth - Set21: Brass M8x12mm belt pulley
Brass pulley
| Quantity |
Description |
Link |
| 4x |
SET 21 - behemoth brass M8x12mm belt pulley |
Mellow 3D |
Aluminium Parts
| Quantity |
Description |
Link |
| 1x |
SET 22 - behemoth Toolhead Back Plate |
Mellow 3D |
| 1x |
SET 22 - behemoth Toolhead Top Plate |
|
| 1x |
SET 22 - behemoth CPAP Duct Slider |
|
Screws
| Quantity |
Description |
| 2x |
M2x10mm SHCS |
| 2x |
M3x3mm SHCS |
| 8x |
M3x6mm SHCS |
| 4x |
Low-Profile M3x6mm |
| 4x |
M3x8mm SHCS |
| 6x |
Low-Profile M3x8mm |
| 3x |
M3x12mm SHCS |
| 4x |
M3x16mm SHCS |
| 4x |
M3x40mm SHCS |
Locknut
| Quantity |
Description |
| 2x |
M3 Locknut |
Washer
| Quantity |
Description |
| 2x |
M3 Washer |
Threaded Insert
| Quantity |
Description |
| 6x |
M3 Threaded Insert (M3x5mmx4mm) |
Aluminium Bushings
| Quantity |
Description |
| 2x |
M3 Bushing 3.1mm ID x 6mm OD x 10mm |
| 4x |
M3 Bushing 3.1mm ID x 6mm OD x 35mm |
Warning
Before ordering belt clamps for your 3D printer, confirm whether your build uses 9 mm or 12 mm belts.
SET23 is designed for 9-10 mm belts.
SET24 is designed for 12 mm belts.
behemoth - Set23: 9-10mm Belt Clamp
Laser Cut Stainless Steel
| Quantity |
Description |
Link |
| 2x |
SET 23 - behemoth 9-10mm Belt Clamp |
Mellow 3D |
behemoth - Set24: 12mm Belt Clamp
Laser Cut Stainless Steel
| Quantity |
Description |
Link |
| 2x |
SET 24 - behemoth 12mm Belt Clamp |
Mellow 3D |
Tip
The behemoth Toolhead is specifically designed for use with the mammoth-3D Hell Fire Hotend. However, it can also support other hotends when used with the universal adapter.
Please review the following options carefully before placing your order:
Set 25: Designed exclusively for the Hell Fire Hotend and is not compatible with other hotends.
Set 26: Includes the universal hotend plate, allowing compatibility with a range of hotends such as the Rapido, Goliath Air, Goliath Water, and Tricorn hotends.
Note: The Chube Hotend is currently not supported.
behemoth - Set25: Hell Fire Water cooling Plate / Mounting Plate
Aluminium Parts
| Quantity |
Description |
Link |
| 1x |
SET 25 - behemoth Hotend Water Block |
Mellow 3D |
| 1x |
SET 25 - behemoth Hell Fire Hotend Mount |
|
Screws
| Quantity |
Description |
| 4x |
Heat Break Screws |
| 4x |
Heat Break Nuts |
Bearings
| Quantity |
Description |
| 1x |
3mm Bearing |
Press fit adapter
| Quantity |
Description |
| 2x |
Press fit adapter for 2mm ID x 4mm OD |
behemoth - Set26: Universal Hotend Plate and Duct Mounting Plate
Aluminium Parts
| Quantity |
Description |
Link |
| 1x |
SET 26 - behemoth Universal Duct Plate |
Mellow 3D |
| 1x |
SET 26 - behemoth Universal Hotend Plate |
|
mammoth-3D - Set28: Hell Fire Hotend 150 Watt
Hell Fire Hotend
| Quantity |
Description |
Link |
| 1x |
SET 28 - Hell Fire Hotend |
Mellow 3D |
Thermistor
| Quantity |
Description |
| 1x |
550C Thermistor |
Screws
| Quantity |
Description |
| 2x |
M2x3mm SHCS |
SLM Titanium Shield
| Quantity |
Description |
| 1x |
Hell Fire Shiel |
Heat Brak
| Quantity |
Description |
| 1x |
Hell Fire Heat Break |
| 1x |
Hell Fire Heat Break Cover |
Kevlar Sock
| Quantity |
Description |
| 1x |
Hell Fire Kevlar Sock |
V6 Nozzle
| Quantity |
Description |
| 1x |
0.4mm V6 Nozzle |
